Cutting busbar fabrication machine PS-CWC series

fixed

HYDRAULIC BUSBAR CUTTING MACHINE Performance and characteristics - Adopts a single side type structure, providing relatively large cutting power. The waste material blade is made of alloy tool steel, forged and ground for durability. The incision is neat, with no burrs and no deformation. - When cutting copper and aluminum busbars, there is no need for positioning. Any position can be cut, and a pressing device is equipped on the blade side to prevent lifting of the copper or aluminum busbar. Model Specifications: - PS-CWC-150V: Output 200 KN, Trip 70mm, Cutting range Copper & aluminium Rows ≤150x12 mm, Weight 23kg - PS-CWC-200V: Output 230 KN, Trip 90mm, Cutting range Copper & aluminium Rows ≤1200x12 mm, Weight 28kg Availability: Usually ships within 4 weeks Technical Specifications / Features - Structure: Single side type - Blade: Alloy tool steel, forged and ground - Cutting Power: 200 KN (PS-CWC-150V), 230 KN (PS-CWC-200V) - Trip: 70mm (PS-CWC-150V), 90mm (PS-CWC-200V) - Cutting Range: Copper & aluminium Rows ≤150x12 mm (PS-CWC-150V), ≤1200x12 mm (PS-CWC-200V) - Weight: 23kg (PS-CWC-150V), 28kg (PS-CWC-200V) - Pressing device to prevent lifting of busbar during cutting
