Hydrostatic grinding machine H seriescenterlessfor tubesPLC-controlled

hydrostatic grinding machine
hydrostatic grinding machine
Add to favorites
Compare this product
indicative price

Characteristics

Type
centerless
Applications
for tubes
Control type
PLC-controlled
Other characteristics
high-precision, hydrostatic
Power

1,300 W, 1,800 W, 2,900 W (1.8 hp)

Spindle speed

Min.: 10 rpm (63 rad.min-1)

Max.: 300 rpm (1,885 rad.min-1)

Description

Features 1. Hydrostatic Bearing Series (H series) Hydrostatic bearings of the grinding spindle are surrounded by high pressure oil film, eliminating metal-to-metal contact, overheating, oil leakage since no oil seals are utilized, providing less power consumption, high rigidity and high vibration damping performance. 2. Hydrodynamic Bearing Series (Economical) Fine hand scraped hydrodynamic bearings made of steel and phosphor bronze alloy with oil lubrication, firmly maintains grinding spindle high precision rotation and rigidity to stand heavy duty grinding in minimum gap.
