Bulk material Venturi ejector Venturi System

for conveyorlow-noise levelportable

Overview
A Venturi system (eductor) conveys continuous trim and small die-cut waste to a collection point by generating a high-velocity airstream based on fluid-dynamics principles. It operates without a chopping fan and with minimal moving parts, making it suitable where dust generation must be minimised or where conveyed materials present an explosion risk.

Key advantages and uses

• Continuous conveyance of trim and small die-cut waste without chopping.
• Suitable for applications where dust creation must be reduced or where explosion hazards exist.
• Available as a standalone Mini System or integrated into existing waste extraction systems to increase air volume and pressure at specific points.
• Can discharge directly into a metal collection cage, reducing the need for downstream separation or chopping equipment.

Benefits

• No moving parts in the Venturi unit itself, reducing maintenance requirements.
• Easy to install with a straightforward, compact design.
• Compact and portable — suitable for varied industrial locations and relocatable if required.
• No contamination of waste by chopping, improving recyclability and value.
• Reduced dust generation compared with chopping-based systems.
• Handles a wide range of waste materials.
• Lower noise levels than chopping systems.

Applications
Trim extraction and waste handling for printing, board, paper, plastics and foil industries. Can be used as a standalone unit or to support existing extraction systems where additional air volume/pressure is required.

Notes
The Venturi system helps reduce contamination of recyclable waste and can lower system costs through simplified design and fewer moving parts.

Technical specifications

• Operating principle: Venturi / eductor creating high-velocity airstream (fluid dynamics)
• Designed to transport continuous trim and small die-cut waste
• No chopping required (no chopping fan necessary)
• No moving parts in the Venturi unit itself
• Can discharge directly into a metal collection cage
• Available as standalone Mini Systems or integrated into larger waste extraction systems
• Reduced dust generation and reduced contamination of waste
• Suitable for hazardous areas or processes with explosion risk (where chopping is undesirable)
• Compact, portable and easy to install
• Lower maintenance and reduced wear due to simplicity of design
