Hydraulic cut-off saw SH 50

pneumaticfor plasticsfor metals

Product overview
SH 50 is a single-head rising saw designed for cutting profiles with a 500 mm blade. The cutting table rotates manually over a range of ±22.5° with 5 fixed angle positions. Intermediate angle settings are read on a graduated scale on the table; a digital display is available as an option. The machine is equipped with a 4 Hp blade motor and spray lubrication. Blade rise is controlled by a hydro-pneumatic cylinder with a precision adjustment to tune blade exit speed according to the profile type.

Features

• Steel construction suitable for industrial cutting
• Blade motor: 4 Hp with spray lubrication
• Hydro-pneumatic blade rise with precision adjustment
• Manual profile table rotation ±22.5° with 5 fixed angle positions
• Angle reading: graduated scale on cutting table; optional digital display
• Profile clamping: 2 vertical cylinders with high/low pressure system; optional 2 horizontal cylinders to reach 4
• Optional laser pointer for profile positioning

Ideal for

• PVC
• Aluminium

Technical specifications

• Model: SH 50
• Blade diameter: 500 mm
• Blade motor power: 4 Hp
• Profile table rotation range: ±22.5°
• Fixed angle positions: 5
• Angle reading: graduated scale on cutting table; digital display optional
• Blade rise: hydro-pneumatic cylinder with precision adjustment
• Lubrication: spray lubrication
• Profile clamping: 2 vertical cylinders (high/low pressure); optional 4 cylinders with 2 horizontal
• Optional accessories: digital angle display, laser pointer
• Construction: steel construction suitable for industrial cutting
