Product overview
The SRHKRLFIRE 2‑wire outdoor strobe is a DC‑operated visual alarm device with a red lens, engineered to deliver a very bright red visual alarm that exceeds the performance of AS ISO 7240.23 listed devices.
The unit is UL listed for wall and ceiling mounting in wet environments and provides eleven user‑configurable brightness settings. Rear‑mounted switches enable on‑site brightness selection.
The device includes a plug‑in mounting plate allowing wiring installation and continuity testing before fitting the strobe. A shorting spring in the mounting base ensures electrical continuity when the device is not plugged in; a captive mounting screw secures the unit to the plate.
The strobe is supplied with a weatherproof plastic back box for line‑in/line‑out wiring. The back box features removable side flanges, 3/4" threaded conduit entries top and bottom, and 19 mm rear knock‑outs.

Key features

• Weatherproof to NEMA 4X and IP56
• Eleven switch‑selectable brightness settings (marked: 15, 15/75, 30, 75, 95, 110, 115, 135, 150, 177, 185)
• Red lens (reduces effective candela; see note)
• Compatible with 24 V DC and 24 V FWR systems; limited operation on 12 V systems at specific settings
• Mounting plate with shorting spring permits wiring continuity check before installation
• Tamper‑resistant, plug‑in design with minimal intrusion into the back box
• Compatible with Pertronic fire panel Warning System and External Bell outputs
• UL listed to UL 1638 for visible signaling devices (public mode)
• Flashes when supplied with correct DC voltage and polarity

Brightness note
The SRHKRLFIRE is fitted with a red lens that reduces flash brightness by approximately 85% relative to the candela markings on the device. For example, the setting marked "185" corresponds to about 27 candela with the red lens.

Ordering information
Product code: SRHKRLFIRE — IP66 strobe, red body and lens (includes decal). Availability: Discontinued.

Technical specifications

• Model: SRHK (product code SRHKRLFIRE)
• Type: 2‑wire outdoor strobe, DC‑operated
• Supply: 24 V DC (compatible with 24 V FWR); 12 V DC with limited brightness settings
• Brightness: Eleven selectable settings (15; 15/75; 30; 75; 95; 110; 115; 135; 150; 177; 185) — red lens reduces marked candela by ≈85%
• Maximum example: setting "185" → ≈27 candela with red lens
• Lens color: Red
• Ingress protection: NEMA 4X; IP56; UL listed for wet environment mounting
• UL listing: UL 1638 (visible signaling devices)
• Mounting: Plug‑in mounting plate; shorting spring; captive mounting screw; weatherproof back box with removable flanges, 3/4" threaded top/bottom conduit entries, 19 mm rear knock‑outs
• Construction: Tamper‑resistant; minimal back‑box intrusion
• Compatibility: Pertronic fire panel Warning System and External Bell outputs
• Operation: Flashes on correct DC supply voltage and polarity
• Regulatory: Not listed under AS 7240
