Lubricated vacuum ejector piSTAMP COAX® MICRO Ti05-2x2single-stageindustrial
Add to favorites
Compare this product
Characteristics
- Lubrication
- lubricated
- Number of stages
- single-stage
- Applications
- industrial
- Ultimate vacuum
0.81 bar
(11.75 psi)- Operating temperature
Min.: 0 °C
(32 °F)Max.: 50 °C
(122 °F)- Weight
49 g
(1.73 oz)
Description
Ultra-lightweight decentralized ejector with integrated release function
Release function based on Exhaust Block principle (EBR), suitable for fast cycle speeds.
The EBR-function can be manually activated with a built in EBR-button.
Two different ejectors to choose between.
Ejector with STX nozzle gives extra fast response and a faster release function. Also recommended in very dirty/dusty environments.
Ejector with Ti nozzle for extra high vacuum flow.
Generic design and mounting interface, suitable for end-of-arm-tools and suction cup holders used in automotive press-shops.
O-ring sealed vacuum port (non-threaded).
