Storage tank CFP
for the food industrystainless steelcylindrical

storage tank
storage tank
Add to favorites
Compare this product


Characteristics

Function
storage
Product applications
for the food industry
Material
stainless steel
Type
cylindrical
Capacity

Max.: 50,000 l
(13,208.603 gal)

Min.: 2,500 l
(660.43 gal)

Description

MODEL : Available in a capacity ranging from 2 500 up to 50 000 l, the CFP Mix storage tanks are used downstream Mix tanks for the powder incorporation processes in the dairy and food industry. APPLICATIONS : Main benefits of the CFP tanks come from the original design of the Pierre Guerin agitation system which includes one stage of patented HTPG4 three blades impeller and a Ti turbine fitted at the lowest part of the shaft: The HTG4 impeller ensures the homogeneous suspension of the mix at low rotation speeds during all the hydration phases of the powders, bringing optimum preservation of the product. The absence of mechanical guide in the tank bottom allows for an optimum cleaning in place and avoids any abrasion from the product. The combination of the TI turbine to the bottom angle (30 or 45°) provides the guarantee of a full drain-ability of the tank (no product retention). On request the tanks can be insulated and / or jacketed. DESCRIPTION : Stainless steel cylindrical vessel fitted with low speed mixer. Insulation and jacket on request. APPLICATIONS : Homogeneous holding of mix, hydration of powders for the preparation of recipes.
