Portable dew-point meter DewMaster

chilled mirrorwith data loggerwith LCD display

Description
Dewmaster Koffer ProChem Analytik® is a portable dew point mirror analyzer using field-tested chilled-mirror (dew point mirror) technology. The instrument accepts one-, two- or three-stage Peltier sensors (cooling ranges 45°C, 65°C or 95°C) which are user-exchangeable. Each device is delivered with a NIST traceable certificate. Measurement control and configuration are available via the front graphic display, front keyboard and RS232 interface. Multiple analog and serial outputs plus a pressure sensor input enable psychrometric calculations and integration into process systems.

Highlights / Features

• Field-tested dew point mirror (chilled-mirror) measurement principle
• Replaceable 1-, 2- or 3-stage Peltier sensors for different cooling ranges (45°C, 65°C, 95°C)
• NIST-traceable certificate supplied with every unit
• Control menu via front graphic display, front keyboard and RS232
• Automatic calibration function (ABC) with automatic mirror assignment correction and automatic optics adjustment
• Selectable interval for automatic optics adjustment to reduce measurement errors caused by contamination
• Two user-programmable alarms (configurable as hold alarm or normal alarm, Form C)
• Serial (RS232) and multiple analog outputs; programming via RS232 or front keyboard
• User-scalable outputs: 0–5 VDC, 0–10 VDC, 4–20 mA, 0–20 mA — up to 3 simultaneous outputs; scalable to psychrometric variables
• Pressure sensor input for psychrometric variable calculation

Specifications overview (from product tables)
Parameters: Moisture %, Temperature °C, Dewpoint °C, Frostpoint °C
Method: Dew Point Mirror (chilled mirror)
Range: at 25°C: -75°C – +100°C; -50°C – +100°C; -40°C – +60°C
ATEX: No
SIL: No
Accuracy: ±0.2°C TP; ±0.1°C TP optional
Resolution: 0.1 °C
Flow rate: 0.25 – 2.5 l/min
Pressure: up to 20 bar
Calibration: Moisture Generator; NIST certificate supplied
Response time T90: 1.7°C / sec
Gas temperature: -40°C – +100°C
Output: 3 × 4–20 mA; RS232; Alarm; Datalogger optional
Supply Voltage: 90 V – 220 V
Display: Graphic display
Protection Class: IP65
Connection: 6 mm
Dimensions: 52 × 20 × 43 cm
Weight: 5 Kg

Characteristics / Technical specifications

• Product name: Dewmaster Koffer
• Brand: ProChem Analytik®
• Technology: Dew point mirror (chilled mirror)
• Measurable variables: Dew point, Frost point, Moisture %, Temperature, Psychrometric variables (with pressure input)
• Sensors: 1-, 2- or 3-stage Peltier sensors (cooling ranges 45°C, 65°C, 95°C)
• Outputs: Analog (0–5 VDC, 0–10 VDC, 4–20 mA, 0–20 mA), 3 simultaneous outputs, RS232, alarm relay
• Accuracy: ±0.2°C TP standard; ±0.1°C TP optional
• Resolution: 0.1 °C
• Response time (T90): 1.7°C / sec
• Flow rate: 0.25 – 2.5 l/min
• Pressure rating: up to 20 bar
• Calibration: Moisture Generator; NIST certificate supplied with each device
• Display & Control: Graphic display; front keyboard; RS232 programming
• Power supply: 90 V – 220 V
• Protection class: IP65
• Connection: 6 mm
• Dimensions: 52 × 20 × 43 cm
• Weight: 5 Kg
