Straight-toothed sprocket wheel KSSGS2-13carbon steel
Add to favorites
Compare this product
Characteristics
- Teeth
- straight-toothed
- Other characteristics
- carbon steel
- Diameter
Min.: 20 mm
(1 in)Max.: 26 mm
(1 in)
Description
Module 2, 13 Tooth Ground Steel Pinion Shaft
Qty Range1 – 910 – 2425 – 4950 – 99100+
Price/Unit$88.79$84.97$81.18$77.42Request For Quote
Lead Time2 wks2 wks2 wks3 wks
Product Specifications
(Dimensions shown are for reference only, please refer to our catalog page for precise technical data.)
MaterialHardened Carbon Steel
Quality ClassCommercial
No. Of Teeth13
Stem Length ( Left)30.00 mm
Stem Length ( Right)120.00 mm
Pitch Dia.26.00 mm
Stem Dia.20.20 mm
Face Width20.00
Module ( Pitch )2.000
Pressure Angle20.0 °
Catalogs
No catalogs are available for this product.
See all of Quality Transmission Components‘s catalogsOther Quality Transmission Components products
Spur Gear Pinion Shafts
