Generators from the SDG series are compatible with all ultrasonic welding devices from the Easy series and their actuators, as well as the ABW series, lots of special actuators, all cutters and all hand units.
They can be programmed in the dialogue box, have robust housing and are very reliable.
SDG generators can be placed in a multirack to operate up to five module simultaneously with large systems.
Softstart and softstop function
To gently augment and attenuate the oscillations of complex horns to protect these from damage.
Increase process reliability
A part counter and a reject counter are integrated into all ultrasonic generators from the SDG series.
With continuous use, the generator may require cooling under certain circumstances. A fan has already been integrated into the generator.
The SDG ultrasonic generators can be used to set a wide range of limits that issue a warning or stop the machine.
Operating frequency: 20 kHz, 30 kHz, 35 kHz, 40 kHz or 70 kHz
Power output: 100 W, 200 W, 400 W, 500 W, 750 W, 900 W, 1000 W, 1500 W or 2000 W
- Time mode
- Energy mode
- Time and Energy mode
- Time or Energy mode
- Continuous mode
- Contact cut-off
Communication and interfaces:
- Digital I/O
Power supplies: 230 V ± 10 %, 50 / 60 Hz
Amplitude: Adjustable 40 - 100 %, changeable in 1 % increments
Weight: 16 kg
