Characteristics
- Type
- belt
- Operating mode
- continuous
- Product applications
- packaging machine
- Other characteristics
- for packaging lines, mobile
Description
BELT FEEDER
TECHNICAL FEATURES
MACHINE INDEX 50, INDEX 65
power supply: 400 V.3 -Ph -50HZ +T / 400 V.3 -Ph -50HZ +T
infeed speed (m/min): 22
power installed (kW): 0,2
tape width (mm): 50
machine weight (kg) : 73 / 80
manual cycle or automatic : STD
manual cycle start by pedal or push-button: STD
length x width x height (LxW) min. (mm/inches): 150x110 / 5,9x4,3
length x width x height (LxW) max. (mm/inches) ∞x500 / ∞x19,7 ; ∞x650 / ∞x25,5
H max (mm/inches) 922 / 36,2 ; 922 / 36,2
W max (mm/inches) 705 / 27,7 ; 855 / 33,6
L max (mm/inches) 1040 / 40,9 ; 1120 / 44
working height (mm/inches) 670-850 / 26,4-33,5 ; 670-850 / 26,4-33,5
