compact zero-point clamping system
The SPEEDY connect series are fast closing clamps made of high-quality tool steel and a housing made of anodised, high-strength aluminium with very low space requirements due to compact external dimensions. The system is clamped mechanically using springs, the force is boosted pneumatically and the system also released pneumatically. The SPEEDY connect is self-locking due to the integrated spring assembly.
The integrated polling unit acquires and signals the clamping state via three signals (“clamped without nipple”, “nipple clamped” or “released”) on LEDs on the rear of the element, as well as digital signals for forwarding to a higher-level controller. The polling is designed so it is resilient to interference and is suitable for use in welding systems.
