Tandem road roller 13 000 kg ( 28 660 lbs ) | SW900
vibratingarticulated

tandem road roller
tandem road roller
tandem road roller
Add to favorites
Compare this product


Characteristics

Type
tandem, vibrating
Specifications
articulated
Operating weight

13,000 kg
(28,660.1 lb)

Motor power

124 kW
(168.59 hp)

Description

Efficiency The 4,000vpm high frequency setting is especially effective for Superpave compaction. With this high frequency mode, the compaction work is sped up and a smoother surface is achieved due to closer impact spaces. The directions of vibrator's rotation are arranged so that all effective compaction force is applied to the ground and uncomfortable vibration does not reach the operator station. Easy operation and operator comfort The 180 degree rotating MPOS (multi-position operator station) provides all around visibility as well as a view of drum edges regardless of the direction of travel. The rotation of the operator station is smooth and effortless. The instrument panel is always located in front of the operator so that the monitoring of gauges and instruments is very easy. The pressurized and fully corrosion-proof water sprinkler system includes two large capacity polyethylene tanks which have a large filler opening, stainless pipes and quick-mount type brass spray nozzles along with a triple filtering system. This system includes an emergency back up when a water pump fails or one tank becomes empty. The wind protection cover for each spray bar keeps drums constantly wet even on windy days. This protective guard is provided for each tank. Excellent serviceability The engine and hydraulic components are protected in a fully enclosed compartment with wide service doors. In addition, these components are accessible from the ground. The hydraulic system includes centralized pressure gauge ports.
