Resistance tester SXZR-10A

stator windingfor transformersUSB

SXZR-10A is single phase DC winding resistance tester which designed specifically to measure DC resistance values of transformer windings and any DC resistance of an inductive device. Features ♦ Controlled by high speed SCM, easy to use. ♦ Selectable current positions, large measurement range, suitable for the DC resistance values measuring of large-medium transformers. ♦ Full protection functions to ensure safety and availability. ♦ Auto discharging and discharging indicator. ♦ Intelligent power management technology, small consumption, less heating. ♦ 320X240 True color LCD screen. ♦ Built-in thermal printer. ♦ Perpetual calendar, 1000 groups’ data storage no lost even power failure. ♦ RS232 and USB interface, easy communicate with PC and U disk. Specifications Output current:<5mA, 40mA, 200mA, 1A, 5A, 10A Max. resolution:0.1μΩ Measuring range: 100Ω-20KΩ (<5mA) 1Ω-250Ω (40mA) 100mΩ-50Ω (200mA) 5mΩ-10Ω (1A) 1mΩ-2Ω (5A) 0.5mΩ-0.8Ω (10A) Accuracy: ±0.2%(±2digits) Power Source: AC220V±10%，50HZ±1Hz Working temperature: 0~40℃ Working humidity: ＜90% RH, no condensation Oversize: L400mm X W200mmX H280mm Weight: 12KG (Including test leads)
