OU-802SF is a high performance silicone free thermally conductive compound and will not dry out. It has low viscosity for easy and neat application. OU-802SF is applicable to silicone sensitive devices.
The proprietary formulation of OU-802SF makes for its good thermal conducting performance. Together with its superior wetting properties in filling surface irregularities, OU-802SF provides a cost effective solution for application where rapid heat transfer from heat source to spreader is required.
OU-802SF is RoHS compliant and halogen-free, offering extra reassurance in applications where hazardous substances are forbidden.
Color -
Dark Grey
Thickness Range [inch/(mm -
–
Density [g/cm³] -
2.85
Thermal Conductivity [W/mK] -
3.5
Operation Temperature [°C] -
-30°C~125°C
Halogen-Free [under 700ppm] -
Yes
