Cable coiler CableCoiler 1450

coilfor wireautomatic

The CableCoiler 1450 is a single pan coiling system that is used to coil wire, cable or tubing. It features a rotary design with moveable pins to adjust for different coiling diameters. Another unique feature of this design is the easy unloading scheme, using retracting coiling disc with and an automatic safety cover lift. The machine works in “auto coil of loose rings” mode as an integrated post processing accessory for use with cut and strip machines. Programmable parameters: Cable parameters ( diameter, length in offline mode) Coiling parameters (inner/outer diameter) Configuration parameters (distance after cutting, speed synchronization adjustment, etc.) Programmed parameters can be saved in jobs for easy and fast loading (by UI or even barcode scanner) for operation Jobs can be imported/exported between coilers by USB stick Function As the coiling disc rotates, the material is coiled around the inner pins When the coiling is completed, the coiler pulls out the material from processing machine and stops The coiling disc raises up and takes the coiled material out of the pins while the safety shield opens automatically so the operator can easily remove the coil The unique design of coiling system ensures the safety protection during operation by doing all the rotating movements in a down position with closed and monitored cover
