Radial supercapacitor SCCA

for printed circuit boardsradial leadenergy storage

Product Overview

• Series: SCCA
• Coin cell supercapacitor
• Radial design
• THT terminals

Unique Selling Proposition

• Very compact design
• High power density
• Low leakage current
• Long lifetime

Applications

• Sensors
• Small mobile devices
• Smart meters
• Computers and peripherals
• Office equipment
• Real-time clock (RTC) backup

Variants (short table)
Capacity (DC, 25°C) [mF] | Capacity Tolerance | ESR max. (AC@1kHz) [Ω] | Order Number
100 | -20% +150% | 50 | 3-158-694
220 | -20% +100% | 40 | 3-158-695
330 | -20% +80% | 40 | 3-158-696
470 | -10% +30% | 40 | 3-158-697
1000 | 0 +30% | 15 | 3-158-698
1500 | 0 +30% | 10 | 3-158-699

Packaging
100 - 470 mF: box (265x190x90 mm) with 44 plastic tubes (255x15x15.5 mm) of 17 pieces each
1000 - 1500 mF: box (265x190x90 mm) with 32 plastic tubes (255x22x16 mm) of 11 pieces each

Approvals and Compliances (high level)
Approval Reference Type: SCCA
Compliances: CE declaration of conformity, UKCA declaration of conformity, RoHS (2011/65/EU and Amendment (EU) 2015/863), China RoHS (SJ/T 11363-2006), REACH (Regulation (EC) No 1907/2006).

Technical data

• Rated Voltage: 5.5 V
• Capacity: 100 - 1500 mF
• Capacity tolerances available: -20% +150%, -20% +100%, -20% +80%, -10% +30%, 0 +30%
• ESR max. (AC@1kHz): from 10 Ω to 50 Ω depending on variant
• Leakage current max. (72 h, 5.0 V, 25°C): from 3 µA to 12 µA depending on variant
• RMS current (25°C): values from 18 mA up to 118 mA depending on variant
• Peak current max. (25°C): values from 25 mA up to 133 mA depending on variant
• Operating temperature range: -25 °C to 70 °C
• Storage conditions: 0 °C to 60 °C, max. 70% r.h.
• Mounting: PCB, THT
• Soldering methods: Wave
• Weight: 3.1 - 8.4 g (depending on variant)
• Terminals material: Tin-plated
• Packaging units: see Packaging above
