Electrical CAD software Cavi 3D

simulationmachinefor cables

3D Cables Length 3D cable length simulator - Useful for machine builders and / or automatic lines The module allows you to easily draw a path for the Cables with a 3D polyline, in a vacuum or directly on a 3D model, imported using STEP files in SPAC Automazione. The 3D Cables Path features place on the model the utilities previously drawn in the diagram with simple drag & drop operations. Afterwards it is possible to analyze the model created to obtain the lengths of the conductors, with the intent to search for the shortest routes. The 3D scheme generated in this way is then navigable and can be consulted in detail via the 3D PDF, generated by the appropriate optional SPAC Automazione module. In addition, the calculated lengths will appear in the material list.
