NTC thermistor SM Series

SMD

Standard SMT NTC Thermistor (SM Series) SM series thermistors come in package sizes including 0402 through 1206, have an operating temperature range from -40°C to 125°C, are available most typically with a base resistance of 10K and with a Beta of 3435K (25/85), can be supplied with tolerances to ±1.0% at 25°C, and are supplied on tape and reel. RoHS Compliant. Specifications Custom Thermistors: For Custom SM Series Thermistors - contact Selco Standard Size: 0402, 0603, 0805 Resistance at 25ºC: 1K Ohms to 100K Ohms Beta: 3435K, 3975K, 4390K (25ºC/85ºC) Tolerance at 25ºC: ±1% to ±5% Temp Range: -40ºC to 125ºC Below are some example part numbers with application specific probe housing, lead wire details, overall length, etc. These assemblies are typically RoHS compliant. SM-0603-F010K-1T NTC surface mount thermistor, 10K Ohm base resistance at 25°C, Beta of 3435K (25/85), tolerance of ±1.0% at 25°C, overall length 1.60 mm, width is 0.80 mm, thickness is 0.70 mm, with end band width of 0.20~0.50 mm. Tape and reel packaged. SM-0805-F010K-3T NTC surface mount thermistor, 10K Ohm base resistance at 25°C, Beta of 3435K (25/85), tolerance of ±3.0% at 25°C, overall length 2.00 mm, width is 1.25 mm, thickness is 1.20 mm, with end band width of 0.20~0.60 mm. Tape and reel packaged.
