Hall effect joystick JH35

analogsingle-axisswitch

Magnetic-type Joysticks - Hall effect joystick - Compact structure - Redundant signal output - Connected by connectors General Specifications - Operating angle: Approx.±30°from center position - Operating force: Approx.2.3N~3.4N - Max. operating force: 50N - Mechanical life expectancy: Approx.5000,000 - Operating temperature range: -30℃~+70℃ - Storage temperature range: -40℃~+85℃ - Mass： Approx.45g - Protection grade: IP66 (Electrical parts) Electrical specifications - Input voltage /Output signal /Current consumption (no-load)/Load resistance/Output deviation at both ends 5V input, 0~100%VCC output, 100KΩ,<1%.Vcc 15~30V input, 0~10V output, 100KΩ,<50mV 15~30V input, 4~20mA output, <35mA,<600Ω,<0.1mA ±12V±10%input,-10~+10V output,100KΩ,1000MΩ(500V.D.C.) - EMS: 10V/m(80MHz~1GHz,1KHz 80%) EN61000-4-3:2006+A1:2010 Special Specifications - PWM, RS485, CANopen, USB, Modbus, wireless conmunication(LoRa), other digital signal, bus signal, etc. - With customer-specific connectors, With protection module - - - - - - - - - - - - - - - - - - - - - JH35 be customized in accordance with your special requirements. Please contact us at [email protected] for customization.
