Medium excavator SE210-9

crawlerTier 3construction

Configuration selling point The machine is equipped with a dedicated large-displacement engine, coupled with a precisely calibrated high-end hydraulic system. The percentage throttle control allows for precise matching of various machine actions, resulting in smooth operation and enhanced fuel efficiency. Ease of maintenance and operation comfort The engine hood opens backward with lightweight and has a wide opening to facilitate convenient maintenance. The fuel filter elements are centrally located near the right-side door, making maintenance easy. The coolant refilling and the replacement of air filter elements are easily accessible. Adaptability to diverse working conditions The reinforced design of structural components ensures high reliability. The machine offers an easy combination with booms, bucket rods, buckets, and other attachments of varying specifications to adapt to diverse working conditions. External dimensions(mm) - 9625*2800*3075 Bucket rod digging force(kN) - 92.5 Bucket digging force(kN) - 127 Rotating speed(r/min) - 0-11 Maximum digging height(mm) - 10095 Maximum digging distance(mm) - 9860 Emissions (Indicated as per international standards) - Eu stage II
