1.With the benefit of saving water, saving energy, increasing production and saving labor.
2.Compact and easy to operate
3.Precise drainage mechanism ensures that the layout of PE pipes is tightly and evenly distributed.
5.All key parts are treated with hot dip galvanization with long service life.
6.Easy to move the whole machine and well-adapted.
7.According to the actual situation of soil, water drop diameter and intensity of irrigation can be adjusted to protect soil structure and avoid soil erosion.
8.Improve the production conditions of local agriculture,and save labor and increase production.
Dimensions(mm) 4500X2500X2500
PE pipe diameter(mm) 75
Effective irrigation length(m) 300
Weight without water(T) 1.6
Weight with wate(T) 2.5
Chassis wheel tread(mm) 1500-1800
Chassis height (mm) 260
Nozzle pitch(mm) 1300-2800
Nozzle height(mm) 1100
Nozzle diameter(mm) 18-24
Sprinkler range(m) 20-35
Maximum sprinkler width(m) 70
Matched power(Kw) 11
Incoming pressure(Kpa) 550-750
Nozzle flow(m3/h) 13-45
Control area(hm2 14-20
Wheel irrigation period(D) 7
Irrigation depth(mm) 10-40
