Shaft balancing machine PHC-1100

universal

Application The drive shaft balancing machine is a special equipment used to check the unbalance of various drive shafts. Feature - The brackets designed by Jianping can transmit mechanical force, which is firm and reliable, with low vibration damping and good rigidity. - The sensor has good linearity, durable and reliable. - Jianping Electronic measurement system, friendly HMI. One Piece Drive Shaft Balancing Machines Technical data at a glance PHC-100, PHC-350, PHC-1100, PHC-3500 - Max Mass of Workpiece (kg): 100, 350, 1100, 3500 - Effective length of workpiece(mm): 2000, 2000, 3000, 3000 - Max Diameter of Workpiece(mm): Φ130, Φ130, Φ400, Φ400 - Shaft tube diameter of workpiece(mm): Ø120, Ø120, Ø300, Ø300 - Motor Power(KW): 1.5, 2.2, 3, 5.5 - Universal joint torque(N.M): 60, 60, 300, 300 - Min Achievable Residual Unbalance Amount(e mar ): ≤2.5g - Once reduced rate (%): ≥90 1) Stepless speed regulation 2) Frequency conversion - Application: Checking unbalance of drive shafts - Brackets: High rigidity, low vibration damping - Sensor: Good linearity, durable - Measurement system: Electronic, user-friendly HMI - Models: PHC-100, PHC-350, PHC-1100, PHC-3500 - Max Mass: 100kg to 3500kg - Effective Length: 2000mm to 3000mm - Max Diameter: Φ130mm to Φ400mm - Shaft Tube Diameter: Ø120mm to Ø300mm - Motor Power: 1.5KW to 5.5KW - Universal Joint Torque: 60N.M to 300N.M - Min Residual Unbalance: ≤2.5g - Once Reduced Rate: ≥90% - Speed Regulation: Stepless - Frequency Conversion: Yes
