water-jet cutting machine / for composite materials / for ceramics / for metal

Add to MyDirectIndustry favorites
Compare this product Don’t compare this product
water-jet cutting machine water-jet cutting machine - 2040BA


  • Material:

    for composite materials, for ceramics, for metal, for plastics, for glass, for stone, for acrylics, for carbon steel

  • Technology:


  • Product handled:

    sheet metal, panel

  • Control type:


  • Associated function:

    drilling, multi-function

  • Applications:

    for the automotive industry, for metal fabrication, for aeronautical applications, for thin sheet metal, for thick sheet metal, ultra thin glass

  • Other characteristics:

    automatic, high-precision, bridge, 5-axis

  • X travel:

    Max.: 6,000 mm (236 in)

    Min.: 1,500 mm (59 in)

  • Y travel:

    Max.: 6,000 mm (236 in)

    Min.: 1,000 mm (39 in)

  • Cutting speed:

    6,000 mm/min (3.937 in/s)


High frame bridge style cutting machine is one kind of the bridge style cutting machine. It has a high frame on the cutting table, it makes loading and unloading materials easier. It is suited to the material with large fixed size or the material which is easy to load/unload.
High frame bridge style cutting machine designed by us is with beautiful appearance and reasonable structure. The motion system and the water tank are separated. That allows the whole system running in a more stable circumstance and easy to transport, maintain and recycle abrasive. The length of this cutting machine can be customized to meet any requirements.
Technical Specifications

Structure: Bridge Style
Control System: CNC(Professional Waterjet Control System)
Power Supply: AC 220V 50Hz/60Hz
Max.Loading Capacity: 500kg/m2
Max.Processing Size: 2m^4m
Max.Moving speed: 12m/min

On the basis of traditional bridge style cutting machine, we developed High Frame Bridge Style Cutting Table. It allows we to process extra thick material like stone or metal.
