PBL.4024 - Brushless DC Motor for Bladeless Fans
OVERVIEW
The PBL.4024 is a compact 24 V brushless DC motor for bladeless fan applications. The reference configuration operates over 22-26 V and has a no-load speed of 11,800 rpm. At its maximum-efficiency operating point, it delivers 48 W of mechanical output and 51 mN·m of torque at 9,089 rpm, with a current of 2.78 A.
Its motor body measures Ø41.9 × 59.7 mm, excluding the shaft extension. The outline drawing provides the shaft and mounting dimensions for mechanical integration.
KEY FEATURES
- Brushless DC motor for bladeless fan applications
- 24 V DC nominal voltage; 22-26 V operating range
- 11,800 rpm no-load speed
- 48 W mechanical output at the maximum-efficiency operating point
- Ø41.9 × 59.7 mm motor body; shaft extension shown separately
- Customizable electrical performance and shaft dimensions
REFERENCE SPECIFICATIONS
Model: PBL.4024
Nominal voltage: 24 V DC
Operating voltage range: 22-26 V DC
No-load speed: 11,800 rpm
No-load current: 0.5 A max.
At maximum efficiency:
Speed: 9,089 rpm
Current: 2.78 A
Torque: 51 mN·m
Mechanical output power: 48 W
Motor body dimensions: Ø41.9 × 59.7 mm, excluding shaft extension
APPLICATION AND CUSTOMIZATION
Typical application: bladeless fans.
Power Motor can adapt voltage, torque, speed, current, power and shaft dimensions to suit customer requirements. For selection, provide the fan load, supply voltage, mounting space and operating requirements. Final performance is confirmed for the selected configuration and application.
The accompanying catalog includes product photographs, reference specifications, an outline drawing and a performance curve.
