PBL.52 - 12 V Brushless DC Motor for Air Pump Applications
OVERVIEW
The PBL.52 is a brushless DC motor for air pump applications. This listing covers the 12 V reference configuration, with an operating voltage range of 11-16 V and a no-load speed of 6,400 rpm.
The product photographs and outline drawing show the motor arrangement, shaft and mounting features. Selection should consider the pump's load over its operating pressure range, starting requirements, available power supply and installation space.
KEY FEATURES
- Brushless DC motor for air pump applications
- 12 V DC nominal voltage; 11-16 V operating range
- 6,400 rpm no-load speed
- Shaft and mounting details provided in the outline drawing
- Electrical performance and shaft dimensions can be adapted to the application
REFERENCE SPECIFICATIONS
Model: PBL.52
Reference configuration: 12 V
Nominal voltage: 12 V DC
Operating voltage range: 11-16 V DC
No-load speed: 6,400 rpm
Mechanical dimensions: see outline drawing
APPLICATION AND CUSTOMIZATION
Typical application: air pumps.
Power Motor can adapt voltage, torque, speed, current, power and shaft dimensions to suit customer requirements. Share the pump load, target speed, supply limits, mounting dimensions and intended duty cycle with our engineering team. Loaded performance and thermal requirements must be confirmed for the selected motor and pump combination.
The accompanying catalog provides product photographs, reference no-load data, an outline drawing and an application checklist. Values apply to the reference configuration rather than every motor in the PBL.52 family.
