Dual-axis tilt switch LCA series

1-axiswith alarmwith relay output

Product Description
LCA341 / LCA342 series is a low-cost tilt switch developed by RION for applications such as level safety alarming and platform inclination monitoring. It integrates a relay output with a preset alarm threshold; when inclination exceeds the set value, it outputs a relay signal (drive current 1 A) to operate solenoid valves, buzzers or alarm lights for platform safety. It supports single- or dual-axis measurement, features temperature and linearity compensation, and includes protections against short-circuit, overvoltage and surges. All components comply with industrial application requirements.

Key features (excerpt shown on product block)

• Single/dual axis
• Accuracy: 0.1°
• RS232 configurable alarm angle
• Switch/relay output (drive current 1 A)
• Resolution: 0.01° (table may show 0.05°)
• Bi-directional (positive/negative) output

Scope of application

• Engineering vehicle leveling
• Bridge and dam monitoring
• Minecart / railcar monitoring

Specifications (table)

• Model: LCA341 / LCA342
• Manufacturer / Brand: RION (RION TECHNOLOGY)
• Function: Tilt switch with relay output for level safety alarming and platform inclination monitoring
• Axes: Single or dual axis
• Measure range: ±15°
• Resolution: 0.05° (table); 0.01° mentioned elsewhere
• Accuracy: 0.1°
• Long-term stability: 0.05°
• Zero temperature coefficient: ±0.006 °/°C (-40 to 85 °C)
• Temperature sensitivity coefficient: ≤100 ppm/°C (-40 to 85 °C)
• Power-on time: 0.1 s
• Response time: 0.2 s
• Electromagnetic compatibility: According to EN61000 and GBT17626
• MTBF: ≥50,000 hours
• Insulation resistance: ≥100 MΩ
• Impact resistance: 100 g @ 11 ms, 3 axial directions (half sinusoid)
• Vibration / anti-shock: 10 grms, 10–1000 Hz
• Protection grade: Direct lead IP67; Aviation plug IP65
• Cable: 1 m shielded cable, 4 × 0.4 mm², grease-proof, wide temperature
• Weight: 140 g (without cable)
• Output: Relay output (drive current 1 A) for driving solenoid valves, buzzers and alarm lights
