Memory
DDR4-3200,4*U-DIMM, up to 128GB
Storage
-
4*SATA 3.0
1*M.2 (Key-M, 2242/2280, PCIe x4 Gen4 NVMe/ SATA SSD)
Expansion Interface
-
2*PCIe x16 Slot (1*PCIe x16 Gen4 or 2*PCIe x8 Gen4)
3*PCIe x4 Slot (PCIe x4 Gen4)
1*PCIe x4 Slot (PCIe x4 Gen3)
1*M.2 (Key-E, 2230, PCIe+USB 2.0+CNVi, Wifi+BT)
1*PCI
BIOS
- AMI UEFI BIOS
System
- Windows 10/11, Linux
TPM
- TPM2.0, Optional
I/O Interface
Ethernet
-
1*Intel® i225-V 2.5GbE Ethernet Controller, RJ45
1*Intel® i219-V GbE Ethernet PHY, RJ45
Serial
- 4*RS232, 1*RS232/RS485/RS422, 1*RS232/RS485
USB
-
8*USB 3.0, 5*USB 2.0
Audio
- Realtek® Audio HDA Codec, with MIC/Line-out/Line-in
PS/2
- 1*PS/2 Port (Keyboard & Mouse)
GPIO
- 8*Programmable GPIO
Others
- 1*Case Open Header
Display
Display Interface
1*DVI-D: max resolution up to 1920*1200@60Hz -
1*HDMI 1.4b: max resolution up to 4096*2160@30Hz -
1*VGA: max resolution up to 1920*1200@60Hz -
1*eDP: max resolution up to 4096*2304@60Hz
Multiple Display
- Triple
Mechanical & Environment
Dimension
- 305*244mm
Power Input
- ATX PSU
Temperature - Operation: 0℃~60℃, Storage: -25℃~75℃
Relative Humidity
- Operation: 10%~90%, Storage: 5%~95%, non-condensing
