Automatic case erector EZ-BOX XL

adhesive tapeprecise foldinghigh-speed

Product overview
The EZ-BOX XL is an automatic high-speed case erector engineered for large-size boxes. Developed in collaboration between Combi and SIAT, it converts flat case blanks into square, sealed boxes and is designed for straightforward integration into end-of-line packaging systems.

Advantages

• High throughput: up to 20 bpm
• Fast changeover to minimise downtime
• Consistent square boxes for improved stacking and transport
• Reliable sealing with SIAT K Series taping units
• CE-compliant safety features
• Simple line integration and industrial connectivity
• User-friendly HMI for quick operator setup
• Handles both left- and right-handed boxes with dedicated kit

Key features
Quality Boxes

• 120-blank motorised walk-in magazine with end-of-box detection (optional extension to 220)
• Self-cleaning vacuum cups and positive flap folding for precise squaring
• Compatible with SIAT K Series taping units for secure sealing

Maximum Protection

• Safety shields, interlock switches and photocells for operator protection
• 7-inch touchscreen with intuitive diagnostics and operator utilities

Ultimate Efficiency

• Kit available to process right- and left-handed boxes without overturning
• Industrial connectivity for remote assistance and monitoring

What is an EZ-BOX Case Erector?
EZ-BOX is a family of automated case erectors designed to form flat blanks into repeatable, square and sealed boxes. The line reduces manual forming errors, improves packing stability and lowers packaging costs by increasing consistency and reducing damaged goods.

When to invest
Ideal for operations producing more than ~100 cases/hour or where manual forming limits productivity. Supports multiple case sizes and thinner recycled materials to enable sustainable packaging choices and faster ROI through reduced labour, waste and transport damage.

Box dimensions (mm)
L 200 – 620
W 200 – 500
H 250 – 600

Options

• Siat Connect for remote connection and assistance
• K12 SIAT taping unit (3”)
• Outfeed safety tunnel
• Opposite hand boxes kit
• Extended magazine up to 220 blanks
• Higher work bench (700–800 mm)
• Casters

Technical specifications

• Maximum speed: up to 20 bpm
• Fast changeover system to reduce downtime
• 120-blank motorised walk-in magazine (optional extension to 220)
• End-of-blank detection for magazine loading
• Self-cleaning vacuum cups
• Positive flap folding for square boxes
• Compatible with SIAT K Series taping units
• Safety: CE compliance, shields, interlocks, photocells
• 7-inch touchscreen HMI with diagnostics
• Processing of left- and right-handed boxes without overturning
• Industrial connectivity for remote assistance
• Optional accessories: outfeed safety tunnel, opposite hand kit, higher bench, casters
• Designed for easy integration into packaging lines
