Analog recorder ND45

currentenergytime

The ND45 from Sifam Tinsley. Measurement and recording of over 500 electric energy quality parameters, class A for selected parameters, harmonics and interharmonics up to 51st, energy measurement in 4 tariffs, recording of measurements before and after events (dips and swells), configurable display and web server - these are some of ND45 power analyzer advantages (successor of ND40 analyzer). Features Measurement and recording of over 500 electric energy quality parameters acc. to EN 50160, EN 61000-4-30 standards. Measuring Class A. Analysis of current and voltage harmonics and interharmonics up to the 51st for class I. Flicker 4-quadrant energy measurement in 4 tariffs Monitoring up to 6 additional energy meters with pulse output Recording measurements before and after events (dips and swells) Configurable archives of actual values and events recording. Data archiving on an SD card - memory up to 32 GB. Binary inputs (optionally) Relays, binary or analog outputs (optionally) E-mail messages in case of alarm occurs, Web Server (HTTP protocol), FTP Server, DHCP client Interfaces: RS-485 Modbus Slave, Ethernet 100 Base-t (Modbus TCP/IP Server), USB device & host. IEC 60870-5-104 communication protocol for data transmission in industrial process control systems and energy sector. Time synchronization via external GPS module - STR receiver (option). Automatic synchronization of RTC clock with the NTP time server. External dimensions: 144 x 144 x 104mm
