Wall-mount temperature sensor LCS-Temp

room

Overview
Mobile set – for all-round monitoring of measuring rooms. One application of the LCS climate measuring station is the classification and monitoring of measuring rooms in accordance with VDI/VDE 2627. The LCS-Temp standard set contains eight temperature sensors with factory test certificate in a practical transport case, four tripods and the LCS-Desk software extension. According to the standard, four sensors are also sufficient for pure monitoring. The touchscreen panel PC for wall mounting is ideal for the permanent installation of measuring room monitoring. This is supplied ready to use, with a Linux-based operating system and a special touchscreen-compatible LCS-Desk version.

Key benefits

• Monitoring of climatic measuring room conditions for the environmental variables temperature, air pressure and humidity
• Increases the reliability of measurement results through real-time monitoring
• Supports compliance with quality standards and guidelines in accordance with VDI/VDE 2627 by continuously monitoring the measuring environment
• Offers flexibility and mobility thanks to the practical, mobile device set

Included in the standard set

• Eight temperature sensors with factory test certificate
• Practical transport case
• Four tripods
• LCS-Desk software extension

Installation options

• Mobile set for on-demand monitoring
• Touchscreen panel PC for permanent wall-mounted installation (Linux-based with touchscreen-compatible LCS-Desk)

Applications
Classification and monitoring of measuring rooms according to VDI/VDE 2627; monitoring and qualification of measurement environments to ensure accurate and repeatable measurement results.

Technical specifications

• Environmental variables measured: temperature, air pressure, humidity
• Sensor quantity (standard set): 8 temperature sensors (factory test certificate)
• Minimum sensors for monitoring per standard: 4 temperature sensors
• Accessories: 4 tripods, transport case
• Software: LCS-Desk software extension (touchscreen-compatible version available)
• Permanent installation option: touchscreen panel PC supplied ready to use (Linux-based OS)
• Standard compliance: supports monitoring in accordance with VDI/VDE 2627
