Centrifugal fan CRF series
rooftopextraction230VAC

Centrifugal fan - CRF series - SODECA - rooftop / extraction / 230VAC
Centrifugal fan - CRF series - SODECA - rooftop / extraction / 230VAC
Add to favorites
Compare this product

Characteristics

Configuration
centrifugal
Type
rooftop
Function
extraction
Supply voltage
230VAC, 400VAC
Drive mechanism
with asynchronous motor
Material
galvanised steel
Other characteristics
backward curved, low-noise, IP54, corrosion-resistant
Air flow

Max.: 7,600 m³/h
(268,391.467 ft³/h)

Min.: 650 m³/h
(22,954.533 ft³/h)

Rotational speed

Max.: 1,450 rpm
(9,111 rad.min-1)

Min.: 920 rpm
(5,781 rad.min-1)

Noise level

Max.: 62 dB

Min.: 28 dB

Description

Centrifugal roof fans with low noise level Centrifugal roof fans with low noise and external rotor motor. Fan: • Galvanised steel sheet construction. • Backward curved impeller made of aluminium sheet metal except for models 225 and 250, which are made of galvanised sheet steel. • Bird protection grid. • Folding body for ease of inspection and maintenance. Motor: • Class F motors. External rotor and IP54 protection. • Single-phase 230 V 50/60 Hz, except models 450 and 500, 230 V 50 Hz. • Three-phase 400 V 50/60 Hz, except models 450 and 500, 400 V 50 Hz. • Working temperature: -25 ºC +50 ºC. Finish: • Galvanised steel sheet. On request: • The variable speed drive (VSD) is supplied on request.
