Air filter-regulator AW series

compressed airfor compressorsthread connection

Overview
Space-saving integrated filter and regulator units designed for compressed air systems. These modular components provide accurate pressure regulation and efficient moisture removal within a single compact body.

Features

• Integrated filter and regulator in a single compact body
• Modular design for flexible configuration
• Precise pressure regulation
• Efficient moisture separation and drainage
• Six configurations available to match application requirements

Available options
Port Sizes

• BSP 1/4"
• BSP 3/8"
• BSP 1/2"
• BSP 3/4"
• BSP 1"

Body Sizes

• Body 2000
• Body 3000
• Body 4000
• Body 5000

Metal Guard
Available as an option on selected configurations to protect the bowl and increase service life in harsh environments.

Configurations
AW2000-02 — Port: 1/4" | Body: 2000 | Metal Guard: No | Our Quoted Price: £17.10
AW2000-02U — Port: 1/4" | Body: 2000 | Metal Guard: Yes | Our Quoted Price: £18.38
AW3000-03 — Port: 3/8" | Body: 3000 | Metal Guard: No | Our Quoted Price: £23.86
AW4000-04 — Port: 1/2" | Body: 4000 | Metal Guard: No | Our Quoted Price: £33.56
AW4000-06 — Port: 3/4" | Body: 4000 | Metal Guard: No | Our Quoted Price: £45.10
AW5000-10 — Port: 1" | Body: 5000 | Metal Guard: No | Our Quoted Price: £71.14AW2000-02 — Port: 1/4" | Body: 2000 | Metal Guard: No | Our Quoted Price: £17.10
AW2000-02U — Port: 1/4" | Body: 2000 | Metal Guard: Yes | Our Quoted Price: £18.38
AW3000-03 — Port: 3/8" | Body: 3000 | Metal Guard: No | Our Quoted Price: £23.86
AW4000-04 — Port: 1/2" | Body: 4000 | Metal Guard: No | Our Quoted Price: £33.56
AW4000-06 — Port: 3/4" | Body: 4000 | Metal Guard: No | Our Quoted Price: £45.10
AW5000-10 — Port: 1" | Body: 5000 | Metal Guard: No | Our Quoted Price: £71.14

Technical specifications

• Series: AW Series
• Function: Filter regulator (integrated filter + regulator)
• Supported port sizes: BSP 1/4", 3/8", 1/2", 3/4", 1"
• Body sizes: 2000, 3000, 4000, 5000
• Metal guard: Optional on selected configurations
• Typical use: pressure regulation and moisture removal in compressed air systems
