Oil filter-regulator-lubricator A series

airoil mistwater

Product Overview
Compressed air filters and line lubricators for industrial pneumatic systems. AF filters remove contaminants, water and oil from incoming air. AL lubricators inject a fine oil mist into the airline to extend service life of tools, actuators and valves. Both series are offered in BSP 1/4" to BSP 1" port sizes with standard and guarded bowl variants.

Product Range

• AF Filters & AL Lubricators
• BSP 1/4" – BSP 1" port sizes
• Standard & Guarded Bowl variants
• Air preparation components for pneumatic systems
• Industrial modular design

Configurations
Part Number | Type | Variant | Port Size | Price (GBP)
AF2000-02 | Filter | Standard | BSP 1/4" | £8.86
AF2000-02U | Filter | With Guard | BSP 1/4" | £9.90
AF3000-03 | Filter | Standard | BSP 3/8" | £13.02
AF4000-04 | Filter | Standard | BSP 1/2" | £16.04
AF4000-06 | Filter | Standard | BSP 3/4" | £19.08
AF5000-10 | Filter | Standard | BSP 1" | £34.26
AL2000-02 | Lubricator | Standard | BSP 1/4" | £9.80
AL2000-02U | Lubricator | With Guard | BSP 1/4" | £10.94
AL3000-03 | Lubricator | Standard | BSP 3/8" | £11.82
AL4000-04 | Lubricator | Standard | BSP 1/2" | £16.50
AL4000-06 | Lubricator | Standard | BSP 3/4" | £20.66
AL5000-10 | Lubricator | Standard | BSP 1" | £36.46

Technical specifications

• Function: AF = compressed air filter (removes contaminants, water, oil)
• Function: AL = line lubricator (injects fine oil mist to extend service life of tools, actuators and valves)
• Port sizes: BSP 1/4" to BSP 1"
• Variants: Standard and Guarded (with guard) bowl options
• Available part numbers include AF2000, AF3000, AF4000, AF5000 and corresponding AL series
• Price currency shown in table: GBP
