Resistive touch screen panel PC OM-IPC 12/8

multitouch screen12.1"12"

This extremely compact 12.1" XGA built-in monitor impresses with its excellent brightness value and high contrast value. The brackets attached to the side (optionally above/below) and the integrated power pack guarantee you easy installation in your complete solution. - Housing: OpenFrame - Display size: 12.1" - Resolution: 1024 x 768 XGA - Brightness: 600 cd/m² - Contrast ratio: 1000:1 - Power supply: 90~ 264 V AC - Viewing angle: 178° / 178° - Touchscreen options: Touch resistive - Power supply options: 24 V DC, 12 V DC, 12 V DC ext. Netzteil 230 V AC - Operating System options: Windows 10 IoT Enterprise LTSC, Windows 10 Pro 64-Bit OEM Vollversion - CPU Model options: Intel® Core™ i5 8 GB RAM / 250 GB SSD, Intel® Core™ i7 8 GB RAM / 250 GB SSD, Intel® Celeron® J6412 / 8 GB RAM / 250 GB SSD Areas of application: Monitors and panel PCs can be found in numerous applications such as information displays at train stations, airports, museums, public buildings or hospitals. - MultiTouch industrial monitors - Panel mount (aluminum frame) - Ruggedized, long term available - No edge or steps in front - Flat, smooth front protection against dirt or dust - Attachment above mounting brackets or VESA Branches: (Industry-) Automation, Mechanical and plant engineering, Measurement and control technology, Digital Signage Product also available as Monitor Technical Specifications: - Housing: OpenFrame - Display size: 12.1" - Resolution: 1024 x 768 XGA - Brightness: 600 cd/m² - Contrast ratio: 1000:1 - Power supply: 90~ 264 V AC - Viewing angle: 178° / 178° - Touchscreen: Touch resistive (option) - Power supply options: 24 V DC, 12 V DC, 12 V DC ext. Netzteil 230 V AC - Operating System: Windows 10 IoT Enterprise LTSC, Windows 10 Pro 64-Bit OEM Vollversion - CPU Model: Intel® Core™ i5 8 GB RAM / 250 GB SSD, Intel® Core™ i7 8 GB RAM / 250 GB SSD, Intel® Celeron® J6412 / 8 GB RAM / 250 GB SSD
