Liquid filter SMFS-P-030
hydraulicmobile

liquid filter
liquid filter
Add to favorites
Compare this product


Characteristics

Designed for
liquid, hydraulic
Other characteristics
mobile
Flow

Max.: 30 l/min (7.925 us gal/min)

Min.: 0 l/min (0 us gal/min)

Description

Mobile Filtration System - Type SMFS-U-030 The SMFS-U-030 is a Mobile Filtration System mounted on a robust Steel frame push cart, which means the perfect compromise between flexibility on the one hand and highest nominal flow rates on the other hand. Options and Accessories Replacement Filter Elements ▪ Filter Elements of the Spin-On series SFC-57/58 ▪ Micron rating available from 3 ... 125 μm ▪ Also available with a blank filter element (SFC-5700) for the reason of used oil to be removed from the hydraulic reservoir Clogging Indicator ▪ Visual Pressure Clogging Indicator Type SIM 04 Lance ▪ Length 450 mm / 17.72 in Hose ▪ Available length 3 m / 9.84 ft incl. ports

Catalogs

No catalogs are available for this product.

See all of STAUFF‘s catalogs
