X-ray diffractometer Xstress G3

laboratory

A diffractometer with modifiable movements, giving access to confined spaces and complex geometries. • Non-destructive • Suitable for laboratory, factory and ­field use • Quick assembly, ready to use in 10 minutes • Easy replacement of X-ray tube (Cr, Cu, Co, Fe, V, Ti, Mn) which enables measuring different materials • Three measurement distances as standard: 50, 75 and 100 mm • Two NMOS position sensitive detectors • Instantly adjustable 2θ-angle • XTronic software for running the measurement and calculating residual stresses and retained austenite content (optional) • d-sin²χ and Ω-measurement modes as a standard Features • Two symmetrically positioned NMOS position sensitive detectors • standard detector width 30° • for other detectors see options • 2θ-range of the detectors • continuously adjustable within 110° to 165° • lower angles as option with special detector arcs • Standard measurement distance 50/75/100 mm • Replaceable collimators • short and long collimators with 1/2/3/4/5 mm spot sizes • special collimators available as an option
