Vertical CNC machining center VMC-A850-A1000

3-axiscolumn typeBT 40

X/Y/Z axes adopt heavy duty linear ways for A type machine. It ensures the characteristics of high rigidity, low noise and low friction. High speed feed-rate and contour cutting accuracy are achieved. A central rod guides the counterweight. It ensures no vibration effect for Z axis high speed feed-rate and cutting accuracy. High rigid (ball-screw) provides reliable transmission for high speed processing. Superior rigidity structural offers to achieving precision and lasting performance in heavy cutting applications. The spindle adopts super precision angular contact ball bearings. Spindle speed 8000rpm is standard. A SERIES - X/Y/Z Linear guide ways. X-AXIS ADOPTED ROLLER LINEAR WAY Ensure that the X-axis does not deform when it moves full stroke. In addition, the E-type machine is equipped with a box-shaped guide rail on the Z-axis to keep high rigidity, low noise and low friction, fast feed rate and contour cutting accuracy are realized. Table Table size - mm - 1000x560 - 1150x560 T slots - mm - 18x5x100 - 18x5x100 Travel Spindle nose to table surface - mm - 120~680 - 120~660 Spindle Spindle transmission - - Belt type - Belt type Feed X-Y-Z MOTOR(Fanuc) - kw - 1.8/1.8/2.5 - 1.8/1.8/2.5 X-Y-Z motor(Mitsubishi) - kw - 2/2/3 - 2/2/3 ATC System ATC type. - - Arm type - Arm type Max.tool diameter - Ø(mm) - Ø100 - Ø100 Max.tool length - mm - 200 - 200 X-Y-Z Cutting feed rate - m/min - 10 - 10 Rail Type Rail Type - - - 3-axes Linearways - A seris: 3-axes Linea guideways / E Series:Z-boxway;X-Y linearways Dimensions&others Power consumption - KVA - 15 - 15 Air pressure required - kfg/CM² - 6 - 6
