Desktop enclosure EXHE seriesrectangularaluminumfor PC
Add to favorites
Compare this product
Characteristics
- Construction
- desktop
- Configuration
- rectangular
- Material
- aluminum
- Application
- for PC
- Protection level
- EMC, with EMI shielding
- Other characteristics
- heat sink, extruded
- Width
Max.: 287.5 mm
(11.3 in)Min.: 80.6 mm
(3.2 in)- Height
Max.: 127.5 mm
(5 in)Min.: 30.7 mm
(1.2 in)- Depth
Max.: 384 mm
(15.12 in)Min.: 60 mm
(2.36 in)
Description
Aluminum enclosure equipped with a highly efficient heat-sink top cover.
EMC shielding is achieved by having the unfinished inner sides of the heat-sink top cover, bottom frame and panels, as well as the shielding gasket in contact with one another.
Grooves for M3 sliding nut are built into the heat-sink top cover and bottom frame (140mm or wider). Optional nut is available.
Suitable to be used as a fan-less PC, power amplifier, power supply etc. where heat dissipation and EMC shielded are required.
Specifications
See TAKACHI website for accessories and optional parts.
EMC shielding is achieved by having the unfinished inner sides of the heat-sink top cover, bottom frame and panels, as well as the shielding gasket in contact with one another.
Grooves for M3 sliding nut are built into the heat-sink top cover and bottom frame (140mm or wider). Optional nut is available.
Suitable to be used as a fan-less PC, power amplifier, power supply etc. where heat dissipation and EMC shielded are required.
Specifications
- Material : Aluminium A1050P, extruded aluminium A6063S-T5
- EMC shielded
- 64 sizes available.
- Available in Metallic Silver.
See TAKACHI website for accessories and optional parts.
