Ceramic capacitor UHV
chipSMDultra high voltage

Ceramic capacitor - UHV - TDK Electronics Europe - chip / SMD / ultra high voltage
Ceramic capacitor - UHV - TDK Electronics Europe - chip / SMD / ultra high voltage
Add to favorites
Compare this product

Characteristics

Type
ceramic
Configuration
chip, SMD
Technical characteristics
ultra high voltage
Applications
for power electronics, for switching power supplies, for the aeronautical industry, industrial
Capacitance

Max.: 10,000,000,000 µF

Min.: 0 µF

Description

Product overview
  • Type: Ultra-high-voltage ceramic capacitor (UHV series)
  • Manufacturer: TDK
  • Dielectric: ceramic (MLCC)
  • Function: energy storage and filtering in ultra-high-voltage circuits


Technical specifications
  • Voltage ratings: ultra-high-voltage classes — consult datasheet for specific values
  • Capacitance: low-value capacitances optimized for high-voltage stability; refer to datasheet
  • Construction: monolithic ceramic design for high voltage insulation
  • Available terminations and package types: see product options


Applications
  • High-voltage power supplies
  • Pulsed power and test equipment
  • Medical and scientific instrumentation
  • Aerospace and industrial HV systems


Ordering & customization
  • Standard and custom configurations available on request
  • Packaging: bulk, tape-and-reel or custom packing
  • Lead time and MOQ: consult TDK sales or distributor


Quality & documentation
  • Manufactured to TDK quality processes with electrical testing and traceability
  • Datasheet, test reports and compliance documents available on request
  • Contact TDK technical support for application guidance
