Brush deburring machine TM 700

pre-deburringbrushingmarking

Description
The TM700CNC deburring machine is designed for the processing of cylindrical gears (spur and helical), bevel gears, crowns, shafts and pinions with diameters from 30 mm to 400 mm. It is suitable for small and medium production batches and engineered for a simple, fast setup.

Additional information
Category: AUTOMATIC DEBURRING MACHINES
Publication date on page: 20 November

Features / Technical specifications

• Name: TM 700 (TM700CNC)
• Applications: deburring of cylindrical gears (spur and helical), bevel gears, crowns, shafts and pinions
• Workpiece diameter: from 30 mm to 400 mm
• Rotary table with 6 workstations
• Stations: 1 pre-processing with deburring punch, 2 deburring, 2 brushing, 1 marking with integrated laser marker
• All stations axis-controlled for high repeatability
• Station adjustment in Jog mode
• Positions can be saved in dedicated masks; recalling the program sets tools, clamping system and marking automatically
• Machine dimensions: 2500 x 2300 x 2200 mm
