Addressable alarm control panel TFP series

fireanalogfor hazardous areas

GENERAL SPECIFICATIONS •EN 54-2 and EN 54-4 Certified •Technician and user friendly; easy to install, programming and operation •Supports 1 Loop Capacity •Supports 240 Devices per Loop •Supports up to 72 Zone •Cable distance up to 2,5 Km per loop •Network up to 16 Control panels via RS-485 by TFC-1209 Network Module •Up to 3.480 devices and 1.152 zones by network (Using optional TFC-1209 Network module) •Easy to read, 240*64 wide LCD graphic display and user-friendly interface •Display customize with company logo, contact information, images, etc. - •Same level of accessibility and command sending to all panels via peer-to-peer communication network •Supports uninterrupted and reliable loop communication by FlashLink communication protocol •Advanced panel programming and user-friendly system configuration via TFY-1000 software •Supports Repeater panels TFP-1240 •Supports 12.000 events of alarms, errors, and warnings •Supports 2x independent and monitored siren output. Connection up to 50 conventional sirens without external supply. (If used with Teknim TFS-3192 siren). •Detailed voltage/current information of the panel and loop on the LCD display •Night/Day operation mode •Supports Class A and Class B connections, thus new devices can be easily included in the loop via star connection in mandatory cases required for the Project •Multiple language support TFP-1211 Intelligent Addressable Fire Alarm Panel uses unique FLASHLINK protocol for loop communication which created by Teknim engineers. Supports 1 loop, 240 devices and network up to 16 control panels. It offers stable and reliable solutions for working in harsh environments.
