Hydraulic shear PH series
sheet metal

hydraulic shear
hydraulic shear
hydraulic shear
hydraulic shear
Add to favorites
Compare this product


sheet metal
Plate thickness

1 mm, 1.6 mm
(0 in, 0.1 in)

Working length

1,320 mm
(51.97 in)


The shears offer triple-action shearing which includes relief on both edges of both the fixed and moving blades. The blade design eliminates blade-to-blade friction, provides “bite” to minimize sheet movement under shearing stress and produces double penetration in the cutting action. The shears will handle a 52″ sheet. Max. Rated Capacity – 16 gauge (mild steel) Pexto’s PH-52 & PH-452 features compact, fully-integrated, hydraulically powered units that are ideal for many light gauge shearing applications. Pexto hydraulic power shears feature fast, smooth, oil-cushioned action. Both moving and fixed blades are shearing blades of Hi-Speed steel. One piece cast shear bed is recessed for easy sheet handling. Standard equipment includes a precision rack and pinion back gauge a solid finger guard. The PH-52 & PH-452 also includes front and side gauges, bevel gauges and two front arms. The bed is machined for optional side extension squaring gauge. Features include: Fully enclosed control panel, with magnetic starter, selector switch and relays Single or continuous stroke operation. Heavy duty foot switch. If released anywhere in the stroke, crosshead returns to “up” position. Pressure relief valve to prevent overloading. Electric solenoid hydraulic valve for instantaneous response. Dial stroke control – accessible adjustment with stroke length indicator. Hydraulic power uniformly applied through double-acting cylinders. Note: The PH-52 includes parallel back gauge table gauge, bevel gauge, front arms. Also included are deluxe electric control box and stroke control for single phase electrics.
