Caged roller linear guide FTW series
compact

caged roller linear guide
caged roller linear guide
caged roller linear guide
caged roller linear guide
Add to favorites
Compare this product


Characteristics

Technology
caged roller
Other characteristics
compact
Rail length

250 mm, 320 mm
(9.84 in, 12.6 in)

Rail width

Min.: 22.4 mm
(0.88 in)

Max.: 50 mm
(1.97 in)

Description

The LM Roller is a compact linear guide with high load performance and a mallet type roller able to make infinite circular motions. This product is optimally applicable to machines required for high positioning accuracy, repeatability and rigidity. Multiple rows of rollers are arranged at 90°. These models have two or more rows of rollers, and their cages are shaped to bend at 90°.Each model uses rollers with a diameter 0.7071 times greater than that of the rollers on the flat surface so that model FT or FT-V can be mounted on the 90° V surface at the same height if model FT or FT-V is used on the flat surface.
