TFT replacement monitor LCD12-0038

15"800 x 600panel-mount

This 12.1 "TFT - installation monitor has been designed as replacement for the 14" industrial monitor BC 110 Heidenhain, BC 110B, BC111, BC 110 B and F flat screen HEIDENHAIN controls TNC406/407, TNC415, TNC425, TNC426. With the plug & play principle, electrically and mechanically compatible 1:1, the conversion is quick and easy with a few simple steps.Display Resolution12“ TFT Full Colour active / 800 x 600 PixelBrightness300 cd/m2Frequency15-45 kHz horizontal, 50-75 Hz vertikalSettingvia OSD (On Screen Display)Active area249 x 188 mm (B x H x T)Housing dimentionsCompatibelControlHeidenhain TNC 406/407, TNC 415/425, TNC 426Input15pin./ 2-row D-SUB connectorInput VoltageAC 85-240 VOperation temperature-10°C bis 55°CManufactured according to:CE Industrienorm, EN55022, EN55024
