Automatic sprinkler EA-1

waterextended coveragefor firefighting

Overview The EA-1 Protectospray directional spray nozzles release a cooling spray to limit heat absorption, reduce potential structural damage and prevent the spread of fire to protected equipment. The directional spray is effective for area coverage and is sometimes used in lieu of standard sprinklers where a directed spray is preferred. Depending on water design density, these nozzles can be applied for fire control or extinguishment. Use of an automatic nozzle requires consideration of the response time of the thermal element.

Product details Orientation: Directional
K-Factor: Up to 5.6
Temperature Rating: Up to 500°F (260°C)

Bulb type Bulb type for use in closed head systems

Features

• Wide variety of orifice sizes and spray angles
• For EA-1 Protectospray Directional Spray Nozzles, see TFP800 for technical information and listing details
• UL and C-UL Listed; FM Approved

Benefits

• Effective: Multiple stream options and water droplet sizes to support rapid cooling and fire control.
• Flexible: Offers a range of orifice sizes and spray angles for system design adaptability.
• Proven track record: Tyco® products have protected installations for more than 130 years.

Technical Specification Listings and Approvals: UL and C-UL Listed; FM Approved
Note: See Technical Data Sheet for details
Thread: 1/2-inch
Wrench: W11

Characteristics / Technical specifications

• Model family: EA-1 Protectospray
• Orientation: Directional
• K-Factor: Up to 5.6
• Temperature rating: Up to 500°F (260°C)
• Bulb type: For use in closed head systems
• Listings and approvals: UL and C-UL Listed; FM Approved
• Thread size: 1/2-inch
• Wrench size: W11
• Design notes: Directional spray effective for area coverage; may be used instead of standard sprinklers where directional spray is preferred; can be used for fire control or extinguishment depending on water design density requirements
• Installation note: Use of an automatic nozzle requires consideration of the response time of the thermal element
• Available options: Wide variety of orifice sizes and spray angles
