Engine starter HZE-Y series
pneumatic

engine starter
engine starter
Add to favorites
Compare this product


Characteristics

Type
engine
Drive mechanism
pneumatic

Description

Y - Graduai starter The graduai starter is used in pneumatic circuits where a cut-off in pressure, an abrupt start-up is to be avoided to prevent possible damages to equipment. FUNCTIONING PRINCIPLE: 2 way valve which, in thè stand-by position, allows thè passage of an air reguleted flow. When thè working pressure is reached thè valve allows thè air full passage. Size 1 Part no.HZE1Y10GHZE1Y15G Threaded portG3/8Gl/2 Flow rate (Nl/min)2200 Max inlet pressure (bar-MPa-psi)10-1-145 Min pressure (bar)3.5 Fluidcompressed air Temperature (°C)-20 - 80 Weight (Kg)0,485 (A) = inlet pressure 6 bar. outlet pressure 5 bar - Ap 1 bar
