Flexible video endoscope POLYFLEX

semi-rigidfor remote visual inspection

POLYFLEX - High-Performance Sword-Type Video Scope for Steam Generator Inspections

The POLYFLEX represents the new generation of sword-type video scopes designed for demanding nuclear and industrial inspections. Developed using innovative two-component technology, it combines flexibility, durability, and maneuverability to optimize inspections of steam generators and complex structures.
Thanks to its ultra-thin 2.4 mm head and specialized belt combining vertical rigidity and horizontal flexibility, the POLYFLEX ensures excellent maneuverability in narrow tube bundles.

Key Features

• Designed for steam generator inspection
• Ultra-compact 2.4 mm head
• Two-component polyurethane resin technology
• Dual high-intensity LED lighting with dual redundancy
• 1.8 mm operator channel for retrieval tools
• High flexibility and excellent mechanical strength
• Compatible with specialized manipulators
• Customizable models available

Applications

• Steam generator inspection
• Nuclear inspection
• Corrosion and crack detection
• Foreign object detection
• Inspection of platforms and tubular structures
• Heavy industrial maintenance

Technical Specifications

• Probe length: 2 to 7 m
• Camera head width: 2.4 mm
• Field of view: 120°
• Depth of field: 4 mm to infinity
• Direct view: 0° to -20°
• Video output: Analog, Composite, S-Video
• Resolution: 420,000 pixels
• Minimum bend radius: 50 mm
• Operating temperature: -25°C to +70°C
• Waterproof: Splash-proof

Operational advantages

The POLYFLEX enables fast, accurate, and reliable inspections while reducing downtime and major interventions. Its homogeneous illumination and high image quality facilitate the detection of critical anomalies in sensitive environments.
