CNC drilling and tapping machine DRILLTRONIC DTM

verticalcolumn typeelectric

INTEGRATED DRILLING AND TAPPING MACHINE/CNC/ WITH ARTICULATED ARM DRILLTRONIC 134500 DRILLTRONIC DT134500 Speed adjustment from 125-4500 Rpm Drilling capacity with twist drill1-13mm Drilling capacity with cutter: 20mm Tapping capacity in steel: M3-M8 Course of advancement: 135mm Mechanical speed change : 1 Course of column: 500mm Work area: 1300 mm DRILLTRONIC® is the only integrated drilling and tapping units equipped with an innovative system developed with an articulated arm to give maximum working flexibility. The structure is designed with a technology that can provide smooth and quick placements, ensuring rigidity and precision during machining operations. With the new control system VAPS (Volumec ® Assisted Positioning System) with a touch-screen operator interface, easy and intuitive, you can perform drilling and tapping, to set quotas, without the need of manually tracking used with traditional drills. VAPS system (Volumec ® Assisted Positioning System) Rapid identification of the position of the work piece (search zeros) Intuitive programming of drilling on several points. Planning and saving of drilling cycles Programs execution with assisted positioning of the tool on the work plan. Auto and manual change of drilling speed. Electro-pneumatic locking position is reached with decimal precision.
