Absolute rotary encoder WDGA 58S

magnetic16-bit32-bit

Absolute shaft encoder, magnetic, RS485 Especially for food and beverage industry Acid- and alkaline resistance High pressure / steam cleaning Clamping flange; 16/32-bit Single-turn/Multi-turn; CRC checksum Highlights • Resistance to salt mist (IEC 60068-2-11) succeeded • Protection: IP67 + IP69k (high pressure / steam cleaning) • EnDra®: maintenance-free and environmentally friendly • RS485 • Single-turn/Multi-turn (ST + MT max. 32 bit) • Forward-looking technology with 32 Bit processor • 2-colour-LED as indicator for operating condition Product details Flange clamping flange steel case chrome-plated, magnetic shielding Resolution Single-turn Resolution up to 65,536 steps/360° (16 bit) Multi-turn Resolution up to 32 bit. Max. Permissible shaft loading radial: 100 N Max. Permissible shaft loading axial: 100 N Current consumption: typ. 50 mA Power consumption: max. 0.5 W Current consumption: typ. 80 mA Power consumption: max. 0.44 W Protection class Housing: IP65, IP67; shaft sealed: IP65; (IP40 for K1)
